CONSEW® P1560RBL-18-7DD Two-Needle 18-Inch Long Arm Industrial Walking Foot Sewing Machine with Automatic Functions
FULLY ASSEMBLED | TABLE, MOTOR & STAND INCLUDED
Wheels are not included and are sold separately.
LONG ARM REACH • TWO-NEEDLE STITCHING • INDUSTRIAL MATERIAL CONTROL
The CONSEW P1560RBL-18-7DD/220 is a heavy-duty industrial lockstitch sewing machine designed for businesses that require two parallel rows of stitching on substantial materials.
Its extended 18-inch working area provides additional space between the needle and machine body, making it useful when guiding large upholstery panels, covers, and other bulky textile assemblies.
The compound feeding mechanism coordinates the needle, walking foot, and lower feed to help transport layered materials through the sewing area.
The direct-drive configuration and automatic operating functions are intended to simplify repetitive industrial sewing operations while providing additional operator control.
Key Features
- Two-Needle Lockstitch Configuration: Produces parallel rows of stitching for selected structural and decorative sewing applications.
- 18-Inch Long Arm: Provides approximately 457 mm of working space for handling larger material assemblies.
- Compound Walking Feed: Coordinates needle feeding, walking-foot movement, and lower feeding to help control multiple fabric layers.
- Direct-Drive Servo Motor: The integrated motor arrangement provides electronic sewing-speed control without a conventional external clutch motor.
- Automatic Thread Trimming: The -7DD configuration is described with an automatic thread-cutting function to reduce manual cutting between operations.
- Automatic Reverse Stitching: Supports controlled backtacking for reinforcing the beginning and end of selected seams.
- Automatic Presser-Foot Lift: Electronically assists with lifting the presser foot during supported operating sequences.
- Climbing Assistance: The described climbing mechanism helps the operator manage transitions between uneven material thicknesses.
- Large Bobbin Configuration: Designed for industrial sewing operations where extended thread capacity is beneficial.
- Semi-Automatic Lubrication: Uses a lubrication arrangement intended to support the machine's moving components according to the manufacturer's instructions.
Applications
- Automotive upholstery and seat-cover manufacturing.
- Marine upholstery and protective covers.
- Furniture upholstery and large padded panels.
- Leather bags, luggage, and accessories.
- Canvas, vinyl, and coated textile assemblies.
- Industrial covers, awnings, and similar products.
- Commercial sewing operations requiring parallel seams.
Important: Actual sewing capability depends on material thickness, density, thread, needle selection, needle gauge, and machine adjustment.
Technical Specifications
| Brand | CONSEW |
| Model | P1560RBL-18-7DD/220 |
| Machine Type | Industrial Two-Needle Long Arm Walking Foot |
| Stitch Formation | Double-Needle Lockstitch |
| Feeding System | Compound Feed / Walking Foot |
| Working Area | 18 Inches (Approximately 457 mm) |
| Motor | Integrated Direct-Drive Servo Motor |
| Power Supply | 220 VAC |
| Maximum Stitch Length | 9 mm — Manufacturer Confirmation Pending |
| Maximum Sewing Speed | 2,000–2,500 SPM — Manufacturer Confirmation Pending |
| Needle System | 135×17 (DP×17) — Verify Exact Configuration |
| Needle Gauge | 1/4" to 1" — Verify Installed Gauge |
| Presser-Foot Lift | 9 mm Hand / 16 mm Knee — Confirmation Pending |
| Automatic Thread Trimming | Listed for -7DD Configuration |
| Automatic Backtacking | Listed for -7DD Configuration |
| Automatic Foot Lift | Listed for -7DD Configuration |
| Bobbin Type | U or S — Verify Supplied Machine |
| Lubrication | Semi-Automatic — Confirmation Pending |
| Included Equipment | Machine Head, Motor, Industrial Table & Stand |
| Assembly | Fully Assembled by JMJ Sewing Machines |
| Wheels | Not Included — Sold Separately |
Advantages of the Long Arm Configuration
- Additional Material Clearance: The extended working area provides more space for positioning large sewn assemblies.
- Parallel Seam Construction: Two-needle stitching supports consistent spacing between adjacent stitch rows.
- Layered Material Feeding: Compound feeding helps control material movement during demanding sewing operations.
- Electronic Operating Functions: The described automatic features can reduce repetitive manual operations.
- Industrial Workstation: The complete machine package includes the table, motor, and stand.
Fully Assembled Industrial Sewing Setup
The CONSEW P1560RBL-18-7DD/220 is supplied by JMJ Sewing Machines as a complete industrial sewing workstation.
The package includes the machine head, direct-drive motor, industrial sewing table, and heavy-duty stand.
Our team prepares the equipment through assembly, lubrication, machine adjustment, and sewing-performance inspection.
Please Note: Caster wheels are optional accessories and are not included in the standard machine package.
JMJ Sewing Machines Recommends
The CONSEW P1560RBL-18-7DD is a practical option for upholstery manufacturers and industrial sewing businesses that regularly handle large material assemblies.
Its extended working area is especially valuable when sewing large panels that require more clearance than a standard industrial machine provides.
Our Recommendation: Before purchasing, confirm the needle gauge, material thickness, thread requirements, and electrical supply available in your workshop. The JMJ team can help determine whether this configuration meets your production needs.
