CONSEW® SB-400 Professional Steam Boiler Ironing System with SilverStar SE-2000 Iron
3.5L STEAM BOILER • 4 BAR PRESSURE • PROFESSIONAL GARMENT FINISHING
The CONSEW SB-400 Steam Boiler Ironing System combines a dedicated steam-generating boiler with the SilverStar SE-2000 professional iron to support garment pressing and textile finishing operations.
Designed for tailoring businesses, garment production facilities, and professional pressing stations, this system provides an independent steam source for ironing and finishing compatible fabrics.
The 3.5-liter boiler provides steam pressure up to 4 bar, while the lightweight SE-2000 iron allows the operator to guide the pressing process across garments and fabric sections.
With its pressure-monitoring gauge, integrated protective mechanisms, and detachable iron connection, the SB-400 offers a practical steam-pressing arrangement for professional textile work.
Key Features
- Independent Steam Boiler: The SB-400 uses a dedicated steam-generating unit to supply steam to the professional iron.
- 3.5-Liter Water Capacity: Provides an internal water reservoir for steam generation during pressing operations.
- Steam Pressure Up to 4 Bar: The boiler is rated for a maximum steam pressure of approximately 58 PSI.
- SilverStar SE-2000 Iron: Professional iron weighing approximately 3.5 pounds, designed for garment pressing applications.
- Urethane Rubber Handle: Specially treated handle material helps improve grip and limit heat transfer to the operator's hand.
- Steam Pressure Gauge: Displays boiler pressure using both bar and PSI measurement scales.
- Detachable Electrical Connection: The iron uses a connection designed to simplify disconnection and replacement.
- Dedicated Boiler Heating Element: The steam generator has a rated boiler power of 1,500 watts.
- Professional Iron Heating: The SE-2000 iron has a rated power of 800 watts.
- Integrated Protective Devices: The system incorporates multiple controls designed to respond to excessive temperature, pressure, and low-water conditions.
Professional Pressing Applications
The CONSEW SB-400 is suitable for professional workstations where steam pressing is part of garment preparation, construction, or finishing.
- Garment manufacturing and finishing.
- Professional tailoring and alterations.
- Dressmaking and fashion studios.
- Uniform and apparel production.
- Dry-cleaning and garment care businesses.
- Selected upholstery and textile work.
- Commercial pressing stations.
- Professional sewing workshops.
Fabric Compatibility: Always select the appropriate pressing temperature and steam application for the material. Follow garment care labels and test sensitive fabrics before pressing.
Steam Boiler Safety Features
- Pressure Relief Valve: A protective valve incorporated into the boiler cap is designed to release pressure if other safeguards fail.
- Dual Automatic Thermostats: Two temperature-control devices help regulate heating and prevent overheating.
- Internal Electrical Fuse: Provides an additional protective interruption if the thermostatic safeguards fail.
- Low-Water Protection: The system includes an automatic power shutoff and LED indication when the boiler runs out of water.
- Automatic Pressure Switch: Controls the boiler heating system in response to internal steam pressure.
Technical Specifications
| Brand | CONSEW |
| Boiler Model | SB-400 |
| Iron Model | SilverStar SE-2000 |
| Equipment Type | Professional Steam Boiler Ironing System |
| Boiler Power | 1,500 W |
| Iron Power | 800 W |
| Water Capacity | 3.5 Liters |
| Maximum Steam Pressure | 4 Bar / Approximately 58 PSI |
| Voltage | 120 VAC |
| Frequency | 50/60 Hz |
| Electrical Requirement | 20 Amps |
| Total Equipment Weight | 25.3 lbs / Approximately 11.5 kg |
| Iron Weight | 3.5 lbs / Approximately 1.6 kg |
| Overall Dimensions | 16.5" × 9.5" × 15.4" |
| Metric Dimensions | 415 × 240 × 390 mm |
| Steam Pressure Monitoring | Integrated PSI / Bar Gauge |
| Handle Material | Specially Treated Urethane Rubber |
| Temperature Protection | Dual Automatic Thermostats |
| Pressure Protection | Safety Valve & Automatic Pressure Switch |
| Electrical Protection | Internal Fuse |
| Low-Water Protection | Automatic Shutoff & LED Indicator |
| Iron Connection | Quick Connect / Disconnect Electrical Plug |
| Primary Application | Professional Garment Pressing |
What's Included
- CONSEW SB-400 steam boiler unit.
- SilverStar SE-2000 professional steam iron.
- Integrated boiler pressure gauge.
- Standard connections supplied with the complete steam ironing system.
Additional accessories and replacement components depend on the supplied package. Confirm package contents before ordering.
Electrical & Operating Requirements
Electrical Supply: The SB-400 requires 120 VAC at 50/60 Hz with a manufacturer-listed 20-amp electrical requirement.
Electrical Compatibility: Verify that the intended outlet and electrical circuit meet the manufacturer's requirements before operation.
Water Filling: Follow the manufacturer's instructions for filling the boiler and checking the water level.
Pressure Safety: Never attempt to open the boiler cap while the system is pressurized.
Routine Inspection: Check the steam hose, electrical connections, and protective components according to the manufacturer's instructions.
Professional Operation: Use the equipment according to the operating manual and observe appropriate steam and heat precautions.
Advantages for Garment Finishing
- Dedicated Steam Generation: The separate boiler supplies steam for professional pressing operations.
- Lightweight Iron: The 3.5-pound SE-2000 supports controlled manual pressing.
- Pressure Monitoring: The integrated gauge allows the operator to monitor boiler pressure.
- Compact Equipment Arrangement: Provides steam generation and ironing functions within one workstation system.
- Multiple Protective Mechanisms: Includes temperature, pressure, electrical, and low-water safeguards.
JMJ Sewing Machines Recommends
The CONSEW SB-400 with SilverStar SE-2000 Iron is recommended for tailoring businesses, garment manufacturers, and professional sewing workshops that require a dedicated steam-pressing station.
Its 3.5-liter boiler, professional iron, and integrated pressure gauge provide a practical combination for garment preparation and finishing tasks.
Our Recommendation: Before selecting a steam ironing system, consider your pressing volume, workspace, fabric requirements, and available electrical supply. JMJ Sewing Machines can assist with choosing equipment suited to your production needs.
