CONSEW® 7360RB-3DD High-Speed Single Needle Direct Drive Industrial Lockstitch Sewing Machine with Needle Positioning
FULLY ASSEMBLED | TABLE, MOTOR & STAND INCLUDED
Wheels are not included and are sold separately.
HIGH-SPEED LOCKSTITCH • DIRECT DRIVE • NEEDLE POSITIONING
The CONSEW 7360RB-3DD is a single-needle industrial lockstitch sewing machine designed for professional garment manufacturing and straight-stitch sewing applications.
Its integrated direct-drive motor provides electronically controlled sewing operation, while the needle-positioning system allows convenient needle stopping during sewing.
The machine is intended for light-to-medium garment materials and professional production environments requiring adjustable sewing speed and consistent stitch formation.
Key Features
- Single-Needle Lockstitch: Designed for industrial straight-stitch garment sewing.
- Integrated Direct Drive Motor: Built-in motor design eliminates the conventional external clutch-motor arrangement.
- Electronic Needle Positioning: Allows controlled needle stopping according to supported machine settings.
- High-Speed Sewing: Maximum speed listed as 5,000 stitches per minute.
- Adjustable Sewing Speed: Allows operators to select working speed according to their materials.
- Large Rotary Hook: The supplied description identifies a large-capacity hook and bobbin arrangement.
- Side-Load Bobbin Access: Provides access to the bobbin through the side-loading hook configuration.
- Built-In Bobbin Winder: Allows convenient bobbin preparation during routine sewing operations.
- Stitch Regulator Lock: Designed to help maintain the selected stitch-length setting during sewing.
- Semi-Dry Lubrication: The supplied description identifies a semi-dry lubrication arrangement.
- Safety Tilt Switch: The supplied description identifies a protective switch associated with machine-head tilting.
Applications
- Shirt and blouse manufacturing.
- Trousers and uniform production.
- Casual apparel and sportswear.
- Cotton and polyester garments.
- Selected synthetic fabric blends.
- Light-to-medium garment sewing.
- Professional tailoring workshops.
- Industrial straight-stitch operations.
Important: Actual sewing capability depends on material thickness, needle selection, thread, stitch settings, and machine adjustments.
Technical Specifications
| Brand | CONSEW |
| Model | 7360RB-3DD |
| Machine Type | Industrial Single Needle Lockstitch |
| Number of Needles | 1 |
| Stitch Type | 301 Lockstitch |
| Feed Mechanism | Drop Feed |
| Maximum Sewing Speed | 5,000 Stitches Per Minute |
| Maximum Stitch Length | 4 mm / Approximately 6 SPI |
| Presser Foot Clearance | 6 mm / Approximately 1/4" |
| Needle Bar Stroke | 31 mm / Approximately 1-7/32" |
| Needle System | 16 × 257 |
| Motor | Integrated Direct Drive Servo Motor |
| Needle Positioning | Electronic |
| Power Supply | 110V Single Phase — Listed Configuration |
| Lubrication | Semi-Dry — Listed Configuration |
| Hook Type | Large Rotary Hook — Listed Configuration |
| Bobbin Access | Side Load — Listed Configuration |
| Bobbin Winder | Built-In — Listed Configuration |
| Safety Tilt Switch | Listed in Supplied Description |
| Motor Power | Confirm With Manufacturer |
| Included Equipment | Machine Head, Motor, Table & Stand |
| Assembly | Fully Assembled by JMJ Sewing Machines |
| Wheels | Not Included — Sold Separately |
Advantages of Direct Drive Lockstitch Technology
- Electronic Speed Control: Allows operators to adjust sewing speed according to their production requirements.
- Integrated Motor Design: Eliminates the conventional external clutch-motor arrangement.
- Needle Positioning: Supports convenient needle stopping during sewing operations.
- High-Speed Operation: Designed for professional garment manufacturing and repeated sewing operations.
- Industrial Workstation: Provides a dedicated straight-stitch sewing setup.
Fully Assembled & Ready for Operation
Every CONSEW 7360RB-3DD purchased as a complete industrial package from JMJ Sewing Machines includes the machine head, integrated motor, table, and stand.
Our team prepares the machine through assembly, lubrication, calibration, and sewing-performance inspection before delivery or shipment.
Please Note: Caster wheels are not included in the standard machine package. They are available for separate purchase.
JMJ Sewing Machines Recommends
The CONSEW 7360RB-3DD is recommended for garment manufacturers and professional sewing workshops seeking a high-speed single-needle industrial lockstitch machine with direct-drive motor technology.
Its electronic needle positioning and adjustable sewing speed provide additional control for garment manufacturing and straight-stitch applications.
Our Recommendation: Choose the appropriate needle, thread, stitch length, and machine adjustments according to your materials and production requirements. JMJ Sewing Machines can assist with determining whether this model is suitable for your specific sewing application.
